For centuries, civilizations have harnessed energy from water. However, hydropower often requires large bodies of water to move heavy machinery, confining its use to rivers. But what if the electricity needed to light up your house could be generated from raindrops hitting its roof?
To achieve this, scientists rely on electrical charges created when materials come into contact and then separate, a phenomenon called the triboelectric effect. As an example, rubbing a balloon against your hair gives them opposite charges, causing your hair to stand up and stick to the balloon. Scientists apply the same principle to make droplet-based triboelectric nanogenerators, or D-TENGS, where raindrops slide across negatively charged surfaces. As the droplets move, their positive charges gather near the surface, freeing up their negative charges. When the droplets reach a metal strip called an electrode, these negative charges flow into a circuit, generating electricity. However, water often remains on D-TENG electrode surfaces, blocking subsequent droplets and corroding the device.
Researchers at the China Three Gorges University and the Chinese Academy of Sciences approached this problem by modifying the shape of the electrodes used in D-TENGs. They proposed that a needle rather than a strip would help droplets detach quickly, allowing charge to flow into a device that uses inexpensive components. They called this design a needle electrode droplet-based triboelectric nanogenerator, or NED-TENG.
To build the NED-TENG, the researchers prepared a plastic film using a water-repellent polymer called polytetrafluoroethylene as the negatively charged surface. They inserted a copper wire through the center of the plastic film, protruding 3 millimeters (0.1 inches) from the front side to form the needle-shaped electrode exposed to raindrops. Meanwhile, they attached copper foil to the plastic film’s backside as a second electrode, completing the circuit. The team connected both electrodes to an instrument that measures electrical performance and mounted the components on an acrylic sheet, sealing it with waterproof tape.
To simulate raindrops, the team inclined the NED-TENG at 50° from a table and dispensed tap water drop by drop from 30 centimeters (12 inches) above its plastic film. Like conventional D-TENGs, the device generated electricity as droplets slid across the film and contacted the needle electrode. However, because the water touched only a small area of the needle, it easily slid off the NED-TENG, preventing the water from building up like in D-TENGs.
The researchers then evaluated and optimized the device using 2 metrics: the force driving charges through its circuit, or voltage, and how fast its charges transfer, or current. First, they compared the NED-TENG with a conventional D-TENG. The NED-TENG generated about 564 Volts (V) and 5 milliamperes (mA) of current, nearly twice the voltage and 3 times the current of the D-TENG, and enough to power small electronics like indicator lights.
Next, they varied the droplets’ release height to maximize electricity production. They found that increasing the release height from 10 to 30 centimeters (4 to 12 inches) increased both voltage and current, peaking at about 543 V and 4 mA. At greater heights, droplets splashed hard on impact, scattering the water and disrupting the charging process they observed in sliding droplets.
Similarly, the researchers tested different device inclination angles, ranging from 10° to 70°. Their tests revealed that the device’s electrical performance increased at steeper angles and peaked at 50°, reaching 521 V and 3 mA. At steeper angles, droplets spent less time in contact with the surface, reducing electrical output. They explained that because triboelectric materials are highly sensitive, results can vary slightly between experiments, leading to individual peak values that are lower than the highest overall outputs.
The researchers then explored how the technology might perform in a simulated rooftop installation. To reduce power fluctuations during real-world applications, they connected multiple NED-TENGs. They observed that 10 connected devices could fill a small energy-storage component within 2 minutes and power 200 LED lights.
Overall, the NED-TENGs shed water efficiently and generated more electricity than D-TENGs, while remaining simple to build. The team noted that future upscaled studies should examine how rooftop systems can direct rainwater onto the devices at optimal heights, and how droplets interact with their surfaces to improve long-term performance. With further development, these low-cost systems could turn rooftops into practical generators powered by everyday rainfall.
