Detecting Toxins Produced by Algae

A portable tool for detecting the cyanobacteria toxin responsible for harmful algal blooms in drinking water sources may be soon on its way

Image Credit:

Harmful algal blooms are becoming an increasing problem in areas around the world, including the Great Lakes, where drinking water is obtained from surface water sources, such as lakes and rivers. When agricultural nutrients and urban waste runoff enters these bodies of water, microbes such as cyanobacteria can consume these nutrients and quickly increase in abundance. Cyanobacteria (also known as blue-green algae) produce compounds called cyanotoxins that can be harmful to humans. Microcystins are one group of cyanotoxins that can cause skin rashes, hives, or if swallowed, gastrointestinal symptoms. In extreme cases, liver damage can occur if a large amount is ingested. There are approximately 80 variants of microcystins known, and microcystin-LR is the most toxic.

The World Health Organization assigned a maximum concentration limit of only 1 microgram per liter (µg/L) of microcystin-LR for drinking water sources. If the water contains more than 1 µg/L of this microcystin, the water would be considered unsafe for drinking and would have to be treated. People would have to switch to bottled water for drinking, cooking, or brushing their teeth instead of using the contaminated water, which causes many issues in highly populated urban areas. After a harmful algal bloom, cities need a quick and reliable way to determine whether the water is safe to consume.

Current methods for measuring the toxin microcystin-LR in water, such as High-Performance Liquid Chromatography/Mass Spectrometry, Fourier-Transform Mass Spectrometry (FT-MS), or various types of bioassays are generally expensive, complex, time-consuming, or require expertise to analyze water samples in a laboratory. However, the authors developed a new tool called a graphene film electrochemical sensor (“biosensor”) to directly detect microcystin-LR in water samples. If manufactured on a large scale, this would allow groups to quickly and easily monitor microcystin-LR levels within a lake or river.

Their biosensor was made in the lab by completely coating an electrode with microcystin-LR. They first made a few standards that each contained a different amount of microcystin-LR but the same amount of antibodies specific to microcystin-LR. The antibodies were attracted to the small amounts of microcystin-LR in the solution, but since they added an excess of antibodies, not all could bind to it. When the biosensor already coated in microcystin-LR was added, the remaining antibodies attached to it. The researchers could then measure electron transfer resistance of the antibodies on the biosensor (using a technique called Faradaic electrochemical impedance spectroscopy) to determine the original concentration of microcystin-LR.

To test their new device, they took tap, lake, and pond water samples from Tokyo, Japan and repeated the procedure. Even though the water samples contained organic compounds and metal ions that would be common in most surface waters and might cause interference, these did not impact the biosensor’s detection results, which is promising. To confirm this graphene film biosensor would be just as sensitive as conventional methods, the results were compared to FT-MS results of the same water samples and showed comparable values. The researchers found that this graphene film biosensor was extremely sensitive to microcystin-LR and could detect concentrations down to 2.3 nanograms per liter, which is considerably lower than the World Health Organization limit of 1 µg/L. While more work needs to be done to develop this technology, this sensor is a promising possibility for direct detection and monitoring of drinking water sources at risk for harmful cyanobacterial blooms and microcystin-LR contamination.

Study Information

Original study: Fabrication of graphene film composite electrochemical biosensor as a pre-screening algal toxin detection tool in the event of water contamination

Study was published on: August 6, 2018

Study author(s): Wei Zhang, Baoping Jia, & Hiroaki Furumai

The study was done at: Research Centre for Water Environment Technology, Department of Urban Engineering, The University of Tokyo School of Materials Science and Engineering, Changzhou University, China College of Engineering, Swansea University, Bay Campus, UK. School of Natural and Built Environments, University of South Australia

The study was funded by:

Raw data availability:

Featured image credit:

This summary was edited by: Caroline Vrana
